Digital Engine DE896-FL fanless Embedded Box Computer is the ideal application ready system platform solution which idea for Digital Signage, KIOSK, POS, Thin Client, Projector PC, Media Player, and Vehicle PC. All electronics are protected in a robust housing for embedding into a case, or as a stand-alone application, where space is critical and the environment is harsh.
Compact for everywhere
With dimension 166mm x 157mm x 48mm and 1.25L volume, DE896-FL can apply to many tiny places and small rooms and give you more flexibility.
Real silent & energy saving
The VIA C7/Eden/C7-D CPU just requires up to 20 watts when operation and less than 0.5 watt when idle. Therefore, DE896-FL can run with a 65 watts power adapter with minimal heat generated. With no cooling fan, DE896-FLcan give you a complete silent working condition.
Long term reliability
DE896-FL had 40,000 hour MTBF and passed 8G operation shock and 0.5Grms operation vibration tests. It can apply both vertical and horizontal placement without having thermal issues. These advantages ensure DE896-FL's durability and long tern operation.
Ready for all tasks
E896-FL build with VIA CN896 chipset provides 400MHz FSB and up to 2GB DDRII SO-DIMM memory. DE896-FL ships with a VIA nano-BGA2 C7 1.5GHz CPU which is very energy efficient than any other CPUs from AMD or Intel. With 5.1 channels, USB 2.0, Gigabit LAN, and COM ports are fulfilling various devices expend requirement.
Best economic option
DE896-FL is rich in multitask functions at reasonable cost. It will be your best option for every application conditions!
| Specifications |
| CPU |
Type |
VIA nano-BGA2 C7
VIA C7 1.5GMz CPU inside |
| FSB |
400 MHz |
| Chipset |
VIA CN896 + VT8237S Chipset |
| Memory |
1 x SO-DIMM DDRII 533/667
Max Memory Size: 2GB
|
| Graphics |
Integrated VGA Engine in CN896 Chipset (VIA Chrome9 HC DX9 IGP)
1 x D-Sub Port Connector |
| Expansion Slot |
1 x mini PCI Slot |
| Audio |
Realtek ALC883 HD Audio CODEC on-board
5.1 Channel |
| LAN |
Integrated Realtek Gigabit Ethernet Controller (RTL8111C)
Support PXE Boot
Support Wake on LAN
|
| USB |
Integrated in Chipset
5 x USB 2.0 Ports (2 Rear, 2 Front, 1 Onboard) |
| Chassis |
1 x 2.5`` SATA II HDD / CF disk / SSD Bay |
| Front Panel IO |
1 x Power Button
2 x USB 2.0 Ports
1 x Power Indicator
1 x HDD Indicator |
| Rear Panel IO |
1 x DC 19V Jack
1 x D-Sub VGA Port
2 x USB 2.0 Ports
1 x RS232 Com Serial Port
1 x PS/2 Keyboard (with PS/2 Y cable can support PS2/ KB & Mouse)
1 x RJ45 LAN Jack
1 x Line-In Jack*
1 x Line-Out Jack*
1 x Mic-in Jack
NOTE: * Switch by Utility Software |
| Security |
1 x Kinsington Lock Hole |
| CPU Thermal |
Proprietary Fanless Thermal Solution |
| WatchDog Timer |
1 ~ 255 sec/min |
| Power Management |
Power Loss Resume Feature |
| Adapter |
External 110~240 AC-DC adapter 19V@3.5A 65W |
| Dimension |
WxHxD (mm) |
166 x 48 x 157 |
| WxHxD (inch) |
6.54 x 1.89 x 6.18 |
| Weight |
1.07kg / 2.36 pound (N.W.)/ 2.65 pound (Fully Loaded) |
| Environment |
-20 to 60°C
|
| Environment |
MTBF |
40,000 hrs |
| Operating Temp |
0 ~ 50°C (32 ~ 122°F) |
| Relative Humidity |
95% RH (50C non-Condensing) |
| Operating Vibration |
0.5Grms, Random, 10~500Hz, X, Y, Z 3 Axes, 0.5hr/Axis |
| Operating Shock |
8G, half sine, 11ms duration, X, Y, Z 3 Axes, 6Direction, 3 shocks/direction |
| Certification |
CE, FCC, UL, CB |
| Optional Features |
Optional Wifi
Optional Bluetooth |
| Mounting |
A Pair of Right-Angle L-shape mount included
Optional Dual VESA mounting bracket
|
| OS Support |
Windows XP, Windows XP Embedded, Ubuntu
|
| Resolution |
Support 16:9 Resolution(But not 1080p)
Maximum Resolution: 1920 x 1200 32 bits @ 85 Hz
|
|
|
