| CPU
Type |
|
Intel
Pentium III FCPGA2/FCPGA 533~1.3GHz
Celeron PCPGA2/FCPGA 566MHz~1.1GHz
VIA C3 Processor 600MHz~1GHz |
| Chipset |
|
Intel815EG
(North)
Intel I/O Controller Hub 2 (South) |
| Hard
Drive |
|
Support
one 3.5" UDMA 33/66/100 Hard Drive or One 2.5" UDMA
33/66/100 Hard Drive with mounting kit |
| RAM |
|
2
x 168-pin DIMM Sockets, Support low profile 0.78",
unbuffer, PC100/133 up to max. 512MB SDRAM |
| Video |
|
Intel
815E Graphic Controller, Integrated 4MB display cache
(Dynamic Video Memory 10 to 32MB) |
| Resolution |
|
Up
to 1280 x 1024 (16.7M Colors) at 85Hz
1600 x 1200 (256 Colors) at 85Hz |
| CD/DVD/CDRW |
|
Support
one 5.25" CD-ROM, DVD-ROM, CD-RW or CD-RW & DVD
combo drive |
| Floppy |
|
None
(Optional external USB floppy drive is available |
| I/O
Ports |
|
Front
Panel:
1 x 6 pins IEEE 1394 FireWire port (Lucent FW323
Chipset)
1 x USB 1.1 Port
1 x Ear-phone port
1 x Power & HDD LED
1 x Power Button, Reset Button
1 x MIC Port
Back Panel:
1 x Line Out
1 x DC Input Connector
1 x PS2 Mouse Port
1 x PS2 Keyboard Port
1 x 9 pins Serial Port
1 x 15 pins VGA Port
1 x Parallel Port
1 x RJ45 NIC Port
2 x USB 1.1 Ports
|
| Network |
|
Intel
82562ET 10/100Mbps LAN controller |
| Sound |
|
AC'97
Audio CODEC |
| Physical
Dimensions |
|
5.82"(W)
x 10"(D) x 2.79"(H)
14.8(W) x 25.4(D) x 7.1(H) cm |
| External
AC Adapter |
|
AC
Input: 100-240V Universal autosensing at 1.5A
DC Output: 12.0V, 5A +/-5% (60W MAX) |
| Expansion
Slot |
|
1
x PC-104 Plus Slot, 4x on-board GP I/O header connectors |
| OS |
|
MS-DOS,
Windows 9x/ME/NT/2000/XP, Novell NetWare / UnixWare
1.1 and SCO Unix 4.2 |
