System |
Processor |
Intel FCLGA1151 Socket Tested 8th & 9th generation CPU: i7-9700TE, i7-8700T, i5-8500T, i3-8100T, Pentium G5400T and Celeron G4900T |
Chipset |
Intel® Q370 Core Logic
|
BIOS |
Insyde UEFI BIOS CPU temperature, cooling fan speed, system voltage |
Memory |
Support dual channel(two SODIMM) DDR4 2666/2400 Mhz non-ECC SODIMM
Total memory size up to 64GB |
I/O Interface |
Serial |
- 1 COM RS-232, Optional 2nd COM
|
USB |
- 6 x USB 3.1 (External)
Integrated XHCI and EHCI controllers support six super speed USB 3.1 Gen2 ports and compatible to USB2.0
|
Video |
- Integrated Intel UHD graphics 630 or 610 in processor
|
PS/2 |
- PS/2 Mouse and Keyboard Ports |
LED |
Power, HDD |
Expansion |
Mini PCIe |
Mini PCIe Socket :
- 1 Full-size for PCIe/ USB
- 1 Half-size for PCIe/ USB
|
Slots |
PCI-Express x1 Slot
Optional PCI-Express x4 Slot
(Cannot co-exist with Mini PCI Express Slot and x1 Slot)
|
Graphics |
Interface |
- DVI to VGA : Up to 1920 x 1200 @ 60Hz
- DVI-I : Up to 1920 x 1080 @ 60Hz
- DisplayPort : Up to 3840 x 2160 @ 30Hz
|
Storage |
SATA |
- Supports SATA 6Gb/s and 3Gb/s specification
- Supports 2.5" SATA hard disk drive and solid state drive
- Supports SATA Slim DVD-ROM Combo, DVD-RW drive
|
Storage Device |
- 2 x 2.5" SSD/ HDD Bracket (Internal)
2nd SSD/HDD Slot shared with optical drive
|
Audio |
Audio Codec |
Realtek ALC892 high definition audio CODEC |
Audio Interface |
1 Line-out, 1 Mic-in |
Ethernet NIC |
LAN 1 |
Built-in Intel i219LM 100/1000Mbps Ethernet PHY
Support WOL function |
Power |
Power Input |
Voltage 12V, DC-in |
Power Adapter |
Input universal AC 100~240V; Output DC 12V/84W
|
Others |
Smart Management |
Wake on LAN, PXE supported |
HW Monitor |
CPU temperature, cooling fan speed, system voltage |
Mechanical |
Dimensions (W x L x H) |
146mm x 250mm x 70mm (5.7” x 9.8” x 2.76”) |
Weight |
2.4 kg (5.3 lb) |
Mounting |
- Optional U-Shape mounting bracket
- Optional Dual VESA mounting Bracket
|
Operating System |
Windows 10 |
Supported |
Linux |
Ubuntu 14.04
|
Environment |
Operating Temperature |
0 to 40°C with Hard Disk
0 to 60°C with SSD
|
Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
